20m3 Chemical Liquid Tank Semi Trailer | ||
Product Description Overall Dimension:8630*2500*3250mm Axle Space:4730+1310+1310mm Tare Weight:8000kg Loading Capacity:20000L | ||
20m3 Fuel Tank Semi-trailer with Two Axles | ||
Parameter | Dimension(mm) | 8630*2500*3250 |
Axle Space(mm) | 4730+1310+1310 | |
Tare Weight(kg) | 8000 | |
Loading Capacity(kg) | 20000 | |
Tank Thickness | 5mm | |
Bulkhead Thickness | 5mm | |
Baffle Thickness | 4mm | |
OEM | Landing Gear | single operation |
King Pin | 50#,assembled | |
Axle | 2 units,13T Fuwa | |
Suspension | mechanical suspension | |
Tire | 8 units,11.00R20 | |
Rim | 8 units,8.0-20 | |
Emergency Valve | one 3''stainless steel | |
Ball Valve | one 3''carbon steel | |
ABS | 4S/2M | |
Others | Fire Extinguisher | 2 units |
Tool Box | 1 unit,0.8m | |
Spare Tyre Carrier | 2 units |
